Velotric – Breeze 1

The Breeze 1 is a comfortable, easy-to-use cruiser designed for pure riding enjoyment. Its ergonomic frame supports an upright posture.

Specification

Size Guide

Bike Size: Regular / Large

User Height Range: Regular: 4’11” – 5’8” Large: 5’6” – 6’4′

Electronics

Motor Hub: 750W, 65Nm

Battery: Removable 48V, 13.4Ah (627Wh), IPX7, Certificated by UL 2271

Cell: 18650 cell, Certificated by UL 2580

Charger: 48V, 3.0A Fast Charger

Display: 3.5″ Full color, High brightness, Bluetooth

Sensor: Torque/Cadence Sensor

USB Port: USB Type-C phone charge

Throttle Assist: Trigger-control, removable

Pedal Assist: 3 Modes x 5 Levels

Rear Light: Brake highlight, turn signal

Front Light: 400 LM high-output integrated LED, adjustable angle

Water Resistant: IPX6

App & Apple Find My™: APP OTA & Find My

Drivetrain

Chainrings: 46T, narrow wide chainring

Crankset: Aluminum Alloy, 170mm

Freewheel: 8-speed, 11-32T

Chain: KMC 8-speed

Rear Derailleur: SHIMANO 8-speed

Shift Lever: SHIMANO 8-speed

Brake

Brake: Tektro Hydraulic Disc Brake

Rotors: 180mm front and rear

Brake Levers: Aluminum Alloy, with power cutoff

Wheel

Rims: Double-wall Aluminum Alloy

Front Hub: NOVATEC Aluminum Alloy, 15x110mm thru-axle

Tire: KENDA 27.5×2.2″ eBike puncture resistant tires

Supports

Fenders (Optional): Front and rear full coverage

Rear Rack (Optional): Aluminum Alloy, MIK HD

Pedals: Plastic

Kickstand: Aluminum Alloy, included, rear mount

Certification

UL Certification: UL 2849

ISO Standard: ISO 4210

Frameset

Frame: Triple-Butted Aluminum Alloy

Fork: Aluminum Alloy

Speed & Range

*A 187-lb rider using PAS 1 in Eco mode on flat roads.

Max Speed (Default): 20 MPH

Max Speed Adjustable Range: 12~28 MPH

Class: 1/2/3

Throttle Range: 55 Miles

Pedal Assist Range: 70 Miles

Brake

Brake: Tektro Hydraulic Disc Brake

Rotors: 180mm front and rear

Brake Levers: Aluminum Alloy, with power cutoff

Cockpit

Handlebar: Aluminum Alloy, Ф31.8mm, 660mm(R)/680mm(L)

Grips: Durable ergonomic grips, lockable

Stem: Adjustable, Aluminum Alloy

Saddle: VELOTRIC comfort ergonomic seat

Seatpost: Aluminum Alloy, φ30.9mm, 350mm

Clamp: Aluminum Alloy, quick release

Weight & Load

Bike Weight: 48 lbs

Bike Weight (Without Battery): 40.8 lbs

Max Bike Load: 330 lbs

Rear Rack Load Capacity: 66 lbs

Geometry

Regular

Height: 4’11” ~ 5’8”

Reach: 398mm

Handlebar Height: 1050mm

Wheelbase: 1143mm

Stand-Over Height: 380mm

Min Saddle Height: 745mm

Max Saddle Height: 945mm

Large

Height: 5’6” ~ 6’4”

Reach: 404mm

Handlebar Height: 1070mm

Wheelbase: 1147mm

Stand-Over Height: 380mm

Min Saddle Height: 810mm

Max Saddle Height: 1015mm
